IPlugin script interface

The IPlugin script interface represents a plugin, such as the Sprite plugin. The plugin only exists once in the project: if there are multiple Sprite objects in a project, then each object type is represented with a different IObjectClass.

IPlugin APIs

runtime

A reference back to the IRuntime interface.

isSingleGlobal

A read-only boolean indicating whether this plugin is a 'single global' type, meaning it is added to the project once and then is available globally, such as with the Mouse object.

getSingleGlobalObjectType()

getSingleGlobalInstance()

These calls are only permitted when isSingleGlobal is true. These return the single IObjectClass and IInstance respectively that have been created for this plugin.

isWorldType

A read-only boolean indicating whether this plugin is a world type, meaning it appears in layouts.

isHTMLElementType

A read-only boolean indicating whether this plugin creates a HTML element.

isRotatable

A read-only boolean indicating whether instances of the plugin may be rotated.

hasEffects

A read-only boolean indicating whether the plugin may use effects.

is3d

A read-only boolean indicating whether the plugin is 3D (i.e. has depth on the Z axis).

supportsHierarchies

A read-only boolean indicating whether instances of the plugin may be used in hierarchies.

supportsMesh

A read-only boolean indicating whether instances of the plugin may use the mesh distortion feature.

static getByConstructor(ctor)

Return an IPlugin from its constructor in the C3.Plugins namespace, or null if it does not exist. For example IPlugin.getByConstructor(C3.Plugins.Audio) will return the IPlugin interface representing the Audio object, or null if the plugin is not used in the project.
