Wrapper extensions

An additional feature of Construct's plugin SDK is that it allows bundling a wrapper extension for deeper platform integration. This is currently supported with the following exporters:

  • Windows WebView2
  • Xbox UWP (WebView2)
  • Linux (CEF)

The Windows WebView2 exporter uses a traditional desktop Windows application using low-level Win32 APIs that embeds Microsoft WebView2 to load web content. Similarly the Xbox UWP (WebView2) exporter embeds WebView2 to load web content, but in the context of a Universal Windows Platform (UWP) app. The Linux CEF exporter achieves a similar result but using the Chromium Embedded Framework (CEF) instead of WebView2. These applications can be thought of as a "wrapper" around the web content. Plugins can provide a dynamic link library that extends the wrapper with custom features using the full capabilities of the wrapper application - hence the name wrapper extension. The model is similar to Cordova on mobile, where a Cordova plugin can be used for platform-specific integration and called from JavaScript, performing a similar role to a wrapper extension.

Dynamic link libraries use the extension .dll on Windows and .so on Linux. For brevity this guide will use the term DLL to refer to either of these.

The wrapper extension system uses a minimal message-passing system to send small amounts of JSON data between the Construct plugin and the wrapper extension. This allows them to communicate so the wrapper extension can perform tasks for the Construct plugin that are not normally achievable in JavaScript alone. It is specifically designed for integrating C/C++ SDKs such as Steamworks.

The Construct Addon SDK includes the wrapper extension SDK under the path plugin-sdk/wrapperExtensionPlugin. A wrapper extension works as follows:

  • A Visual Studio 2022 (the Community edition is a free download) solution for Windows, and CMake project for Linux, in the extension subfolder uses C++ code to build a DLL which integrates custom features, such as a C/C++ SDK like Steamworks.
  • The DLL uses .ext.dll (Windows) or .ext.so (Linux) as the file extension. The wrapper application looks for files with this name in the same folder as the executable, and will automatically load them on startup.
  • The Construct plugin bundles the DLL file by calling AddFileDependency() with the type "wrapper-extension". This means when a project using the addon is exported, it will also export the necessary file (e.g. the .ext.dll file for Windows).
  • The Construct plugin can then detect that the wrapper extension is available, and if it is, send messages instructing the wrapper extension to perform certain tasks.

The sample in the SDK implements a wrapper extension that demonstrates returning data from C++ back to JavaScript, and implements an action that shows a message box to the user. This uses the Windows MessageBox API and GTK on Linux.

Messaging

In order to exchange messages, both the wrapper extension and the Construct plugin must set the same component ID. This must uniquely identify your plugin/extension combination. If any other plugin/extension uses the same component ID, it will cause a conflict and one of the plugins will fail.

The wrapper extension should call iApplication->RegisterComponentId() in the WrapperExtension constructor to register its component ID. The JavaScript plugin should call this.SetWrapperExtensionComponentId() in its constructor to register the same component ID. Then the two can exchange messages.

There are two kinds of ways messages can be sent from JavaScript to the wrapper extension: a one-off message, and an async message.

One-off messages

A one-off message is a "fire and forget" scheme: a message will be sent but no attempt is made to receive a result or identify if the operation completed.

A one-off message can be sent from JavaScript with a call this._sendWrapperExtensionMessage("message-id", [params...]). The message ID identifies the kind of message. The second parameter is an optional array of parameters to pass with the message. These must only be boolean, number or string type values. Messages sent from the wrapper extension can be received with this._addWrapperExtensionMessageHandler("message-id", handlerFunc). The handler function is passed an object with a small amount of JSON data sent from the wrapper extension.

A one-off message can be sent from the wrapper extension with a call like:

// C++
SendWebMessage("message-id", {
	{ "sampleString1",	"Hello world!" },
	{ "sampleString2",	"Foo bar baz" },
});

In this case the second parameter is a small amount of JSON data that is passed to the JavaScript message handler. The keys must be strings, and the values may only be boolean, number (double type to match JavaScript's number type), or string. (Strings in the C++ SDK must be std::string or C-style char* in UTF-8 encoding.)

Wrapper extensions receive all messages from JavaScript to the same HandleWebMessage() method. That method receives a string of the message ID, and it's up to the wrapper extension to examine that string and respond appropriately depending on the kind of message. The recommended architecture is to use that method solely to distinguish the kind of message, unpack parameters, and then call a dedicated handler method.

Async messages

JavaScript can also send an asynchronous message to the wrapper extension. (This is only supported for JavaScript - there is not currently any support for the wrapper extension to send an asynchronous message to JavaScript.) This is done by calling this._sendWrapperExtensionMessageAsync() which works similarly to this._sendWrapperExtensionMessage(), except it returns a promise that resolves when the wrapper extension responds to the message. It is a useful way to retrieve data from the wrapper extension, including whether a requested operation completed successfully. It can also be used on startup to perform initialization work.

The wrapper extension receives asynchronous messages the same way as one-off messages, except the asyncId parameter is set to a unique number for the message. In order to respond to the message, it must call SendAsyncResponse() passing the same asyncId the message was received with, e.g.:

SendAsyncResponse({
	{ "sampleString1",			"Hello world!" },
	{ "sampleString2",			"Foo bar baz" },
}, asyncId);

The provided JSON data works the same as with SendWebMessage(), and is used as the value that the JavaScript call to _sendWrapperExtensionMessageAsync() resolves with.

Suggested architecture

It is recommended that as much of your plugin logic as possible is implemented in JavaScript. Only send messages to the wrapper extension to make specific API calls that aren't possible from JavaScript. This way it minimizes the amount of platform-specific C++ code necessary, and ensures as much logic as possible happens in the same place, rather than spread across two codebases. Also, JavaScript is an easier programming language to work with, as it has easier-to-use facilities for async code and avoids the need for manual memory management (while still providing excellent performance).

Strings on Windows

For historical reasons, Windows APIs called from C++ that use strings generally use "wide strings" with UTF-16 encoding. These are strings of "wide characters" which are 16-bit types on Windows. This uses the wchar_t type for a character, and std::wstring for the STL string equivalent (as well as types like LPCWSTR for the C-style equivalent in Windows header files).

On the other hand, most modern software and recent C++ codebases use UTF-8 encoding. This uses the standard 8-bit char type and std::string in the STL (as well as types like char* for the C-style equivalent).

Consistent with the modern style, the wrapper extension SDK uses UTF-8 encoding when dealing with strings. However this means strings must be converted when calling Windows APIs that use wide strings. The SDK provides the utility methods Utf8ToWide() which converts a UTF-8 std::string to a UTF-16 std::wstring suitable for passing to Windows APIs. The c_str() method of STL strings also provides a C-style string that Windows usually expects. The WideToUtf8() method can then also convert a UTF-16 std::wstring back to a UTF-8 std::string, suitable for converting back wide strings returned by Windows APIs. The recommended approach is to use UTF-8 everywhere, and only convert to UTF-16 to call a Windows API that requires it; if the API call returns a UTF-16 string then it should immediately be converted back to UTF-8. This means as much code as possible only uses UTF-8 and UTF-16 is used minimally solely to interact with Windows APIs.

Platform-specific code

You can use the following preprocessor definitions to identify the platform being built and so incorporate platform-specific code. Note these definitions only identify the OS, not the architecture.

  • _WIN32 is defined by Visual Studio for Windows builds
  • __linux__ is defined by gcc for Linux builds

Additional examples

There are real-world examples of using the wrapper extension SDK to integrate SDKs on the Scirra GitHub account, including open-source plugins that integrate the Steamworks SDK and the Epic Games Online Services (EOS) SDK. These should help provide sample code that demonstrates how to build a useful wrapper extension.
