My idea is pretty crazy, but there it is:
Say you have a 64x64 pixel canvas,
Each pixel could be assigned to a value in an array (X is pixel's X coord, Y is pixel's Y coord)
for each XY value, you have something in the format of "255,255,255", a RGB value for each pixel (you can pick individual pieces of this value using the left, mid and right expressions).
Now, the Z axis is the frame of animation, iif you want to work with animations. So, the Z axis would store a different RGB value for each pixel for each frame.
Now, for the drawing detection:
First, create global variables that store the current frame (i'm calling canvas_curframe(num)) and the selected brush color in RGB (i'm calling canvas_brushrgb(string)).
To select a color from a menu, you can do something like
- If color selected is RED -> set canvas_brushrgb as "255,0,0" -
To register where the user draws the colors on the canvas, you can compare the cursor's X and Y coords and assign them to a grid.
- On Mouse Left click hold (or whatever) -> Array set at X = mouse.x, Y = mouse.y, Z = canvas_curframe, value = canvas_brushrgb
Finally, the last step is showing the actual pixels on screen via the canvas renderer an that's the one part I can't help you because I never used the Canvas external plugin, but it gives you options like drawing lines, points and boxes directly, wich you could then save as canvas snapshots and turn into frames. Just google "Construct 2 canvas plugin" and you should find info on it.
