Construct WebGPU status thread

Support for WebGPU in Construct is a major upgrade and involves a great deal of work and some backwards compatibility risk, and also needs WebGPU support from the browser/platform which is not yet supported everywhere. Therefore we are rolling out support for WebGPU gradually in steps. This forum thread will indicate the current status of support for WebGPU in Construct as it will be evolving over time.

Background

For more details about what WebGPU is and what this change means, see these blog posts:

1. A brief history of graphics on the web and WebGPU
2. From WebGL to WebGPU in Construct
3. Introducing Construct's new WebGPU renderer

Addon developers

If you are an effect developer you will need to port any existing effects to WGSL to support WebGPU. For more details about this see the Addon SDK documentation on WebGPU shaders.

Activating WebGPU

For WebGPU to be used in your project, it must be enabled for all four of:

1. The chosen preview/export option
2. The browser engine
3. The local device's software/hardware
4. The project settings

These are described in more detail below.

Export support

WebGPU is being enabled separately for individual export options as they become supported. The list below indicates which options WebGPU currently can be enabled on. In the long term we aim to support all platforms.

• Preview / Remote Preview: supported from r337+
• Web / Construct Arcade: supported from r345+
• Android: supported from r380+
• iOS: not yet supported
• NW.js: supported from r345+
• Windows WebView2: supported from r345+
• macOS WKWebView: not yet supported
• Facebook Instant Games: not yet supported
• Playable Ads: not yet supported

Browser engine support

WebGPU must also be supported by the underlying browser engine. The list below indicates the current support for WebGPU in browsers. We expect that in the long term, WebGPU support will become as ubiquitous as WebGL, as all major browser vendors are actively working on it.

• Chrome/Edge (and other Chromium-based browsers/platforms): currently supported in v113+ for Windows, macOS and ChromeOS. Android is supported from v121+. Linux is not yet supported.
• Safari/iOS: not yet supported
• Firefox: not yet supported

Hardware support

Even with a supported export option on a supported browser/platform, you are not guaranteed to get WebGPU support. This is because it requires relatively modern hardware and software.

There is not currently any real public documentation on what kind of system requirements there are for WebGPU. However Web3DSurvey.com's WebGPU statistics show a sample of support for a range of platforms indicating how prevalent support is for particular platforms. The main thing to note is if you fulfil all these requirements and still don't get WebGPU support, it may be because your system is not supported; in that case try a newer and more up-to-date system if possible.

In the Chrome or Edge browsers you can also visit chrome://gpu/ to see diagnostic information about the GPU and WebGL and WebGPU support.

Project settings

To ensure backwards compatibility, Construct currently leaves WebGPU disabled by default, so all projects currently continue to use only WebGL even if WebGPU is otherwise supported. In order to enable WebGPU for a project, you must currently go to the Advanced section of project properties, and set Use WebGPU to Yes.

The default setting for Use WebGPU is Auto, which currently means disabled in stable releases; however for testing purposes it currently defaults to enabled in beta releases, or if Enable experimental features is enabled in Settings with a stable release. However we intend that once support is reliable enough then Auto will change to mean enabled in all cases, therefore switching all existing projects to use WebGPU automatically with no need to configure it for each project.

Note that if the project uses any third-party effects, these must have been updated to support WebGPU. If unsupported third-party effects are in the project, then you should see a compatibility message identifying the effects when changing the Use WebGPU setting. Contact the addon developer for support if you need an effect ported to WebGPU.

Verifying WebGPU is in use

The easiest way to check that WebGPU is active in your project, meeting all the above support requirements, is to add a Text object to your project and display the PlatformInfo.Renderer expression in it. This will return webgpu when the WebGPU renderer is in use, otherwise it will say webgl1 or webgl2.

Other ways to check are also:

• Open Construct's debugger; the second last item in the debugger subtitle includes the same renderer string as the PlatformInfo.Renderer expression, which will also be webgpu if WebGPU is in use.
• Open the browser console (typically by pressing F12) and look for the console log message indicating Construct's renderer. This should include a line that reads something like "[C3 runtime] Hosted in worker, rendering with WebGPU" if WebGPU is in use; otherwise it will refer to WebGL.

Editor support

You can also enable WebGPU for the Construct editor itself, where it will be used to render the Layout View. This will also use the WGSL variants of effects in the editor. You can enable this in Settings by changing Enable WebGPU in editor to Yes. (Much like the Enable WebGPU project property, this defaults to Auto, which currently means disabled but will in future change to mean enabled.)

You can verify WebGPU is in use in the editor by choosing Menu > About > Platform information. If the editor is using WebGPU, then the Platform Information dialog will list WebGPU information instead of WebGL information.

Issues

If you run in to any problems when WebGPU is active, please file an issue for them the usual way, including following all the bug report guidelines, and stating that the issue is specific to WebGPU.

Known issues

Here is a list of known issues with WebGPU that are currently being tracked.

• Texture upload performance can be significantly worse than WebGL, causing performance issues particularly with Text objects. See https://issues.chromium.org/issues/40273077
• In unlimited framerate mode (full frames), the display becomes janky in WebGPU mode. See https://issues.chromium.org/issues/40066112. Note that if WebGPU is set to 'Auto', it is turned off when setting unlimited framerate mode to help work around this.
• Some Android devices appear to have display corruption when rendering with WebGPU. See https://issues.chromium.org/issues/329702056.
• Intel Gen12 LP GPUs appear to fail to render anything at all in WebGPU mode. See https://issues.chromium.org/issues/330655410.
• See also open Construct issues tagged 'webgpu'

Conclusion

WebGPU is a major technology upgrade for both the web and for Construct. We expect to see some significant benefits to supporting WebGPU, including substantially improved performance in some cases, which should be outlined further in an upcoming blog. However with major new technologies comes some risk, and so we are taking precautions and rolling out support gradually. Be sure to check back here in future as the support status will be changing over time and this thread will be updated accordingly.

Yes, Construct will always fall back to WebGL if WebGPU is not supported for any reason. If enabled it tries WebGPU first, then falls back to WebGL 2, then falls back to WebGL 1.

Now that r380 ships with WebGPU enabled for Android I‘ve done some tests myself and thought I’d share them here :) The results unfortunately weren’t too promising…

The past few system webview updates have brought significant performance improvements for my game for webGL 2, while webGPU causes severe stuttering issues on my 7 Pro test device, as you can tell from these videos. Furthermore, it sometimes causes longer hiccups and especially struggles with displays that support a dynamic refresh rate (disabling this feature improves performance significantly, but it’s still worse than webGL). Performance on my (relatively slow) Galaxy S8 with webGL is a lot better in comparison. iOS webGL performance, while not amazing, is much better too.

I‘m hoping for future webGPU or Construct updates to improve this in the future, but for now I think I‘ll have to disable webGPU for my exports.

I‘ll work on a test project once I have time. But fyi, the "boat scene" in my game doesn’t use any effects and still stutters severely. It‘s just sprites moving, a few animations playing and a few objects running opacity tweens. I think pretty much any construct game using high-res instead of pixel art graphics will reproduce this, on the pixel devices at least.

So I've spent hours trying to replicate my issue of near constant stuttering and it was extremely difficult. For me, objects are at least rendering fine, both in the webview beta as well as the stable version.

Edit: I thought that the Compositing Mode made a difference, in reality, it just didn't use webGPU this time, after reinstalling the web view it did it again. Composition mode also makes no difference for webGL on this device at least.

I've created a test project that stutters sometimes, like once a minute, on my test device but it's not even close to my main project. I'm not sure what the difference is exactly, because I've removed most code and almost all behaviors from the main project as a test and then the performance was fine. However, cpu usage is extremely low across the board in the project so I don't quite get how that could make a big difference. Furthermore, gpu usage is rather high but fine too. What causes the lag spikes according to the graphing tool on android is Misc / Vsync Timeout which is not very helpful but yeah. Also with the refreshrate down to 60 the stutters are far less noticable. The sample project also sits in the drive folder.
